Seven years ago, I designed a pair of FPGA based earrings for my wife. (Totally overkill for this application, I know.) She wore it out last night and it still works! Assembled by my pal @SivaPrakazh. You can read about the project here:

Before #AI acceleration became a priority, #FPGAs changed computing by making hardware reprogrammable after manufacturing. Now an @IEEEorg Milestone, they enabled faster innovation in #networking, modern AI systems, and beyond. Learn more at @IEEESpectrum: bit.ly/IEEESpectrum-F…

Working on reviving the Humble iCE FPGA project...

Quite thrilled to get 6 channel I2S mic + audio on USB UAC1 working on iCE40 FPGA. Only possible because of work by Wang Xuan (link below) which Claude helped me modify. This mic array project is something I wanted to attempt for a long time...

Around 2021, I spent over a year trying to write an introductory book on FPGAs. Ultimately I had to abandon the project because of other commitments. I am now starting to publish projects that I worked on. Here's the first one:

Starting work on Papyr ESP32-C6 - a more compact design...

.@Raspberry_Pi Pico ePaper T/H display - works great, but sleep current is 4mA - it was < ~100 nA on breadboard, so something's off. Hardware is hard.🙂

The PCBs are here...

Papyr 2 prototype - @EspressifSystem ESP32-C6 + 4 color ePaper display 😀

Getting started with ESP32-C6. Interesting architecture with two RISC-V cores...

Building firmware with Codex...

Migrated my website from WordPress back to Jekyll/github (I go back & forth every few years) The difference this time was that it barely took an hour thanks to AI. Pulling data from multiple sources, fixing theme issues, generating placeholders - would've taken me weeks before!

My daughter made this for me... snapVCC is the first piece of hardware I designed, in 2015.

Chennai based online store with funny name 👍🙂

Sleep current in nA range - happy to see TPL5110 do its job...

Almost done with the PCB design...

Not a great soldering job, but things are looking much better with DMG3415U with 2 x AA...

Working on an enclosure...

Need to change the P MOSFET (AO3407) in my circuit - works at 4V but not 3V. Discovered while using the PPK2...

Got a Nordic PPK2 for low power current measurements. Neat little device!
