I've been quiet the last couple of months on what projects I am working on. I am excited to say, very soon, we will release v2.0 of our Ultimate & Premium Template along with a new Revit add-in to help users standardize their content faster and from one central window.

Its always a mess when you get started. You just have to get stuff in there to get a birds eye view before you can organize.

Autodesk "Unistrut profile" on the left. Our Unistrut with accurate dimension and profile on the right.

Working on making better Revit detail components. More control over line weights, easier graphic adjustments, angle settings, and pattern alignment.

Revit stair collection work has begun.

Today is the last chance to get a 40% discount on our products! Use the code 40OFFEVERYTHING at checkout. Link in the bio.

Just a reminder those who want to get 40% off our products have only two days left. Deal ends after March 27th. Use the code 40OFFEVERYTHING at checkout. Link in the bio.

Today we released our new Ultimate Railing Collection! 🥳 To celebrate, customers can use the code 40OFFEVERYTHING to get a 40 percent discount on any of our products. Get it before the end of the week. 👉Link in the bio.

Monday next week we release our Ultimate Railing Collection! We plan to have a mini sale for inquiring minds. Make sure to sign up to our newsletter to get access. 😉 Links in the description.

If we were to pick our top Revit railings that took more effort to set up than all other railings it would be these four. They use multiple techniques like panel balusters, multi handrail/top rail sweeps, custom support placement, nested sub components, and custom hatch patterns.

You know those aluminum fencing you see all around the suburbs of the US? We see it everywhere but no railing families to specify it in projects. March 23rd is when we release our railing collection.

One of the issues our upcoming Revit railing collection address' is post placement and support alignment by clearly identifying families that use a segment based vs continuous line modeling methods for specifying placement.

It's official, March 23rd will be the release of our Ultimate Railing Collection. We are super excited to offer this since railings have always been a struggle for users to setup consistently across projects.

A little color goes a long way for user guides. Using our forthcoming Ultimate Railing Collection to test out our new brand aligned in-Revit user guides.

It can be difficult to understand how railing families are structured. Hopefully this, alongside our breakdowns of each item, will better illuminate WHERE something is modified and how each piece fits together.

@tucker_id A helpful tip I just learned, for rail sweep methods, set the profile to be below the reference plane. However the cutting is then shifted down to be embedded instead and only looks horrible in section.

@BIMTemplate Sometimes it is easier to model other ways. I used the curtain wall tool once. Other times an inplace family (not ideal). Not on stair done as a flexible family (balconies).

Glass railings look so nice...so long as you do not host them up on a stair.

Image compression is a b.

It's a Revit field of dreams (fences). Is this reference too old? 👴

The whole Revit railing fence types are here. 🤺

There is a method to the madness...Sometimes you just have to dump everything and keep it roughly organized until you are at a point to organize it. Obviously not when you are actively collaborating with a team... 240+ Revit railings thus far.
