The next series 400 Bridge Span & Staircases issued for review/approval. This project has been designed with removable panels on the top landings for future Ramp installation #design #steel #teklastructures #trimble #networkrail #bridge

Modelling new steelwork onto an existing structure is always a challenging task. However we always breathe a sigh of relief when we are told we will receive a point cloud survey. Enquiries info@wrightsteeldetailing.co.uk #steel #teklastructures #pointcoudsurvey #steelstructures

That’s a wrap for 2024!. We will be back in the office on the 6th January 2025. We’ve worked on a variety of projects this year including this one that we have just received some photos taken on site. It’s always nice to see the project come to life!. Merry Christmas 🎄

Order received on Wednesday, fully modelled, approved and issued for manufacture on Friday. We found a small gap in between larger projects to get this one completed ✅. #steel #steelprojects #trimble #teklastructures

A small structural staircase fully modelled and issued for fabrication. #steel #TeklaStructures #trimble #steelstructure #staircase

A small extension to an existing school in Kent fully modelled and issued to our client for manufacture #steelstructure #teklastructures #steel #trimble

The design phase is close to being finalised on a project we are currently looking at. Approval drawings will be issued in the coming weeks. AFA Shortlands Station #teklastructures #steeldetailing #steel #bridge #trimble

We don’t usually work on residential properties but this new property being built on the South Coast was too nice not to be part of. We have modelled all of the structural steel required for this new build. #steel #steeldetailing #trimble #teklastructures

The next access for all (AFA) station structure starting to take shape. Initial setting out and modelling progressing this week #steel #teklastructures #trimble #networkrail

Final visuals of a project issued this afternoon for approval prior to manufacture and installation on site #steelstructure #networkrail #teklastructures #trimble

One of our projects was recently installed over the Xmas period. It’s always nice to see photographs taken on site. It makes all the design meetings worth while, from a computerised model to reality #steel #trimble #teklastructures #networkrail

The last project of the year issued to our client for review/approval. Out of office now on until 8th January. All the best for Xmas and the New Year!! 🎄 #steel #steeldetailing #trimble #teklastructures #networkrail

A small extension to an existing station platform. Steelwork to be set at multiple levels along the length #steel #steeldetailing #teklastructures #trimble

The next access for all station structure making its way through the office. The project has a mixture of steel, timber & glazing making up the primary structure. The next step is to add all the secondary steelwork #steel #trimble #teklastructures #networkrail

The next access for all (AFA) Station Bridge issues for review/approval. #steel #trimble #teklastructures #bridge #networkrail

Not many left now at all with another one sold to @Wright_Steel who wants the last couple ..... @plattyphoto @ianimperial @StoneTyres @pt_danny_arnold @NijmanZeetankUK @CinemabarStH @EcclestonArms @StevePrescott1 @PScully13 @Simon_Kenyon We really can't do this without you guys

A small footbridge replacement with a safety cage issued for review and approval. The existing bridge is too badly corroded to be repaired. The exiting ramps are being refurbished and connected to the new bridge. #steel #bridge #steeldetailing #trimble #teklastructures

A 65 metre Overbridge modelled & ready for review/approval. Plenty of splice connection with lots TCB bolts and shear studs. #steel #steeldetailing #trimble #tekla #teklastructures #bridge

A client of ours requested a few 3D isometric drawings of a recently completed project we did for them. This project is having the finishing touches completed prior to opening to the public. #steel #teklastructures #trimble #brentcross

External balcony steelwork for a new apartment complex along with a couple of internal fire escape stairs #steel #steeldetailing #teklastructures #trimble #balconies #stairs
