inciprocal Inc. designs and develops end-to-end asset pipeline for high performance AR/VR applications, eCommerce, VFX and video game industries.

San Francisco, CA Katılım Aralık 2018
54 Takip Edilen1.1K Takipçiler
Sabitlenmiş Tweet
inciprocal
inciprocal@inciprocal·
12-light setup targeted to augment existing photogrammetry rigs with addition of advanced Disney PBR material reconstruction. This particular setup is great for prop and flat 2D material scanning. Compact, portable and could be powered by off the shelf 12V Power banks.
English
7
14
103
19.4K
inciprocal retweetledi
Dmitry Andreev
Dmitry Andreev@and_coder·
Doing some weight stress testing of the DIY XY Stage (xy table). Moving around a 1 gallon of water, that's 3.8 kg, looks just fine. More than enough for any scanning automation (props and flat swatches). The drivers are cold. Don't even need any heatsinks 🙀
English
1
1
3
268
inciprocal
inciprocal@inciprocal·
With the wide availability of CNC parts in many shapes and sizes, it has never been easier to build an automated XY stage for high-resolution PBR material scanning using only a minimal number of components: a couple of linear guides, an MCU, and a pair of drivers.
English
1
4
33
2.9K
inciprocal
inciprocal@inciprocal·
12 light rig with 4 light extensions to capture extra sub surface scattering at glancing angles. Configured for 2D high resolution PBR capture.
English
1
2
17
1.3K
inciprocal
inciprocal@inciprocal·
In cases when scan-time metadata or alignment is not available and you need to properly orient objects with as few clicks as possible here is a simple #Blender script that does just that. Align the camera so the object roughly faces the camera and then perform a gravity drop.
English
1
2
9
1.1K
inciprocal retweetledi
Dmitry Andreev
Dmitry Andreev@and_coder·
Have been playing around with some automated scan alignment under the absence of any related metadata (cameras, registration, etc...). All classical geometric solutions work except they do need some validation from a visual model. Gemini is the best so far, then GPT, then Grok.
Dmitry Andreev tweet media
English
0
1
3
451
inciprocal
inciprocal@inciprocal·
Wrapping up testing and shipping the last order of 2025. This is a lower-end 4-light variant of our standard 12-light rig. This one can't do a single view scan but is more portable and well suited for props though requires significantly more camera positions for quality results.
inciprocal tweet mediainciprocal tweet media
English
0
0
5
560
inciprocal
inciprocal@inciprocal·
2K Games the Minotaur Rig prototype complete and calibrated. This is our most minimalistic and optimized PBR face scanning rig configuration so far. Running 20 Sony A9 III cameras at 60 fps and 16 composite light clusters using IDA Tronic lights.
inciprocal tweet mediainciprocal tweet mediainciprocal tweet media
English
1
0
7
2.7K
inciprocal retweetledi
Dmitry Andreev
Dmitry Andreev@and_coder·
Got some CAD parts of a custom Tilta CPL micro-motor worked out and 3D printed to test the fitting. It's almost injection molding friendly but some modification will be needed for sure. Especially the addition of draft angles.
Dmitry Andreev tweet mediaDmitry Andreev tweet mediaDmitry Andreev tweet mediaDmitry Andreev tweet media
English
0
1
1
517
inciprocal
inciprocal@inciprocal·
@CorneliusWrites The smaller something is and the more "macro" you go, the less it matter as long as it's a continuous light source.
English
0
0
1
18
inciprocal
inciprocal@inciprocal·
A Slim configuration of our Lights v2.0. No lenses, no reflectors. For cases where mass or field of view are prioritized.
inciprocal tweet media
English
2
2
12
1.3K
inciprocal
inciprocal@inciprocal·
That's quite a step from our older stepper-based prototypes that has way to many issues with vibrations and noise. This also has faster speed than an original Tilta servo. After shrinking all electronics down to a couple of chips this may be in product soon.
Dmitry Andreev@and_coder

First pass prototype complete. Got all the gears worked out as well as the PID control optimized specifically for quick 90 degree rotations as fast and as smooth as possible. It now takes Tilta CPL 1/4 of a second to switch with minimal noise. Shrink electronics down next...

English
0
0
6
644
inciprocal
inciprocal@inciprocal·
Calibrating White Balance for multi-cam / multi-light Light Stage-like rigs can be quite tedious. Apart from cameras, there is alight light color variation as well as natural Poisson noise in RAW images that can greatly tint the result requiring a number of samples to converge.
English
0
0
4
740
inciprocal
inciprocal@inciprocal·
Naked eyes can really play a trick on you. Cranking things is to false colors is important to see real color uniformity of lights. As a part of rig assembly and packaging. Most of the things can be corrected in software but it's easier to work with more similar footage than not.
Dmitry Andreev@and_coder

While buying a lot of LED stuff from a factory that supposed to be a single manufacturing batch there are still quite a few spectral discrepancies here and there. Most likely messed up at the packing stage or something. You can see a few that clearly have different temperature.

English
0
0
8
570
inciprocal
inciprocal@inciprocal·
A wide angle view... While the standard 12-light rig is very versatile, the 24-light 180 degree Arc is ideal when scanning through a props of similar sizes and topologies. Once tuned, it's a beast. skfb.ly/oFRxT
English
1
5
28
3.2K
inciprocal
inciprocal@inciprocal·
PBR Capture of Adidas IF6704 with 180 degree 24-Light Arc. 5 Cameras, 24 lights, 2 polarization states (48 shots per position). Sony Alpha 1 electronic 1/30 shutter at 15 fps burst synchronized. The shutter sound is digital, just for exposure indication. skfb.ly/p7Hsu
English
1
5
38
3K
inciprocal
inciprocal@inciprocal·
Setting up some figurine scanning with a 24-Light Arc
English
0
7
21
1.3K
inciprocal
inciprocal@inciprocal·
Simplifying rig calibration in upcoming 1.4.2 #inciprocal Photometry Toolkit release with automatic highlight matching. Once the mirror ball aligned, the entire sequence is automatically mapped into the rig's 3D space with proper light positioning.
English
0
3
24
1.6K
inciprocal
inciprocal@inciprocal·
Scanning with 180 degree 24 light Arc - 5 cameras, 24 positions, 2 poses, 2 polarizations, 11520 shots 200 GB JPEGs total. Under 3 minute capture time for 5x Sony a1 50MP @ 20fps or 2 min with 5x Ximea CB654CG-GP-X8G3 65MP @ 30 fps.
English
1
5
55
4.4K
