You can now access all our past podcast episodes also on our YouTube channel: youtube.com/channel/UCdQO4…

Inside a 3000W Water-Cooled Power Supply with GaN & SiC by ElectrArc240 - AC/DC: Interleaved Totem-Pole PFC - DC/DC: ZVS Phase Shifted Full Bridge youtube.com/watch?v=da9GwX… #PowerSupply #Teardown #WBG

"The design of magnetics components is the easiest place to jeopardise a #PowerSupply design project." ~Robert Mammano, Father of PWM Controller IC Industry Learn to design better #magnetics. Wind your own business!

The most important bit of the right-hand thumb rule is to NOT use your left-hand.

Busbar laser cutting process #busbar #powerenergy #renewableenergy #EVs #powertrain

#Solar #photovoltaic (PV) module prices have fallen almost 500-fold in the last 50 years: From 128.27 $/W in 1975 to 0.26 $/W in 2024. Source: ourworldindata.org/grapher/solar-…

FOSSEE (Free/Libre and Open Source Software for Education) project at IIT Bombay promotes the use of #FLOSS tools in #academia and #research. They're now inviting applications for the Semester-long Internship 2026. DEADLINE: 10 Feb 2026 fossee.in/semester-inter…

Aluminum busbar and nickel strip joined by ultrasonic welding #aluminumbusbar #nickelstrip #RenewableEnergy #EVs #powerbattery

Each of these ultra-compact power supply designs for 800V BEV systems features a planar transformer and showcases the space-saving and reliability benefits of 1700 V SiC-based InnoSwitch3-AQ switcher ICs. okt.to/m40Fju okt.to/CoVe1U okt.to/hLGfAw

Debug the specs "Much of the essence of building a program is in fact the debugging of the specification." ~Fred Brooks, American computer scientist and software engineer Replace the word program with #PowerConverter, and the statement would still be correct.

#CoolingTips Just a little whiff of air goes a long way in cooling your power device! Notice the steep drop in #ThermalResistance of a #Heatsink at low air velocity. Image source: Austin Hughes, "Electric Motors and Drives: Fundamentals, Types and Applications"

The latest data shows that 92.5% of all investments in new electricity generation capacity worldwide went into renewables. [This is for 2024 and comes from IRENA.]

continuing with my PEEC solver in Blender for inductors. Now I have a basic Python/Numba code that can calculate skin and proximity. You can see as the frequency increases the current shifts towards to the outer surface and also gets affected by adjacent turns #b3d #geometrynodes #electronics #Technology #science

"Average #efficiency of crystalline Silicon wafer-based [#solar #PV] modules is 22.7% in Q4-2024." Ref: Fraunhofer #Photovoltaics Report, 31 Oct 2025 Available: ise.fraunhofer.de/en/publication…

How to calculate the voltage undershoot (ΔVo) of an SMPS during a load step (ΔIo)? ΔVo = ΔIo/ (2π fc Co) where fc = Cross-over frequency of the control loop Co = Output capacitance #SMPS #DCDC #DynamicLoading

Perils of split ground planes: Excellent demo by @EMC_Guru Kenneth Wyatt using a near-field probe (NFP) and a spectrum analyser. #EMC youtube.com/watch?v=D2cmAV…

Busbars with PEM stud used in new energy industry #busbars #EVs #greenenergy #electricpower #tinplated

Designing An #OpenSource Power #Inverter Dennis Feucht of Innovatia Laboratories wrote this 25-part article series, published in the @How2Power Today newsletter, starting with part 1 in May 2021 and concluding with the final part in April 2025. how2power.com/pdf_view.php?u…

#Odisha is inviting proposals for a 500MWh standalone #battery energy storage system (#BESS) project. pv-magazine-india.com/2025/12/22/odi…

#PWM is beautiful.

“One good test is worth a thousand expert opinions.” – Wernher von Braun
