Got Joulescope for the lab, as suggested by a few people (we only had Nordic PPK2) I will write a detailed thread about the importance of power consumption analysis in hardware security tomorrow. For now, let's look at Joulescope. It's advertised as "DC Energy Analyzer" Basically it measures power consumption of your device under test. Why would you want to do that? It's important when you design/build a battery operated IoT device. You want to optimize the energy usage. You could measure a device's consumption over time (power profiling), and basically find areas that could be optimized. It could also be useful for security as we'll see tomorrow. It's better than Nordic PPK2 in almost every aspect: more current (3A), better resolution (0.5nA), high sampling rate (2Msps, 16 bit). But all that comes at a price (almost 10x) I also got a USB front panel that could replace the default panel, to make USB device power analysis easier. In the pictures I show a power profile of an OCXO. As you see, during the warm-up phase it draws about 556mA, and after the period, it goes down to about 280mA. I'm still playing with the app, but it has 2 main views: voltmeter and oscilloscope. Btw, the device is assembled in USA and feels high quality.
