wow you can really reach feature size much smaller than wavelength with two photon polymerization (2PP) this sample is from UpNano GmbH, using a green laser at 515 nm

@samschmitz Tip stays inside when you pull the handle

I designed an MRI-safe torque wrench that can be printed in place in a single piece on a Fuse 1+. Doesn’t rely on friction so it keeps 0.6Nm after hundreds of cycles. It works great but has one MAJOR flaw—can anyone guess from the pictures?

@lukeweston @humphilomath @jwt0625 Doesn‘t scale yet*

@humphilomath @jwt0625 You’re not missing anything. Nano 3D printing with 2-photon absorption has the potential to disrupt or replace a lot of other nanofab techniques. It doesn’t scale to full wafer throughput, just like how the industry doesn’t use EBL at prod scale. But it’s such a good R&D tool.

@mechadense @jwt0625 Surely, resolution depends on the objective (+print parameters) used and therefore the speed/cost

@jwt0625 Could this be used to make reversible microclips for 300μm diameter SPM needles for automated needle exchange with a needle magazine? To not … ★ need to replace a non-cheap qPlus nc-AFM sensor ★ be doomed to the tap to fix tip hack ★ be doomed to manual needle fix out of UHV

@jwt0625 Using it everyday, has quite some advantages

@zanehengsperger How much

holy cow factory space in CA is expensive

@YunTaTsai1 Does the new AI5 chip include PWBs?

AI changes the nature of compute, thus it also changes how a chip is built.

@jwt0625 Co-packaged optics should speed this up

transceiver modules and attachment for 16 x 3.2 Tb/s

@jwt0625 How do they dissolve the resist although it has such crazy undercuts

god this looks so fun Smith2021: [High Frequency, Low Loss, Additively Manufactured Hermetic Package](imapsource.scholasticahq.com/api/v1/article…)

what the hell is this polystrata process, bruteforce additive 3d copper components and packages by layers of photolitho + plating + planarization + die attach for embedded components, and rinse & repeat..

@mbpup @jwt0625 Website available? Interested in hearing more

@nemimilo @jwt0625 novel process for micro-scale metal parts

A powerful laser lights stuff on fire, until it does not. ("cold processing" - when a fs-ps laser pulse vaporizes material faster than thermal or mechanical time scale.)

@mbpup @jwt0625 What kind

@jwt0625 nope, still working in extremely niche and wacky 3d printing however

@jwt0625 Using fs for 2pp lithography
