@ghidraninja @RIGOL_Tech You could try the @eevblog forums. Some people there are knees deep in the firmware. The arbitrary waveform file format emerged solving some headache for me (#msg5304760" target="_blank" rel="nofollow noopener">eevblog.com/forum/testgear…), Yes i'm still bitter because @RIGOL_Tech couldn't be arsed to document it.

@pakakezu @RIGOL_Tech Thanks - I have no problems with getting regular waveform data out, however I want to specifically read out the data of a recording (hence :RECord:WREPlay:FCURrent 2) :)

Does someone know whether it's possible to get recorded traces from a @RIGOL_Tech DHO800/900 using SCPI? :RECord:WREPlay:FCURrent 2 :WAV:DATA? ...does not seem to work

@FizzOtter I would be more concerned about moisture control than ESD given they are still in "tape" snippets. And not a sealed outside bag. So baking it is.

@SableSys @arturo182 Nope. As things, stand before you get hands one a sample is already out of stock. So you buy blind and hope for the best if you can buy something similar.

@arturo182 Time for an agile redesign 😎

Oh no

@tedyapo Well given how disorganized i am, sure i will not subtract the parts i used.

@tedyapo Mouse running out of space. Do you want to increase the DPI?

@GregDavill Works with high value MLCC-s too. I thought as cap expands, the voltage increases reaching the opening voltage of the LED. It can be "reset" with a multimeter in diode mode.

Weird phenomenon, during reflow some green LED power indicators are emitting slightly. Seems like maybe during reflowing solid polymer caps there is an effect of creating a small electrical current? Does anyone know what this effect is called? Maybe some further reading?

@arturo182 @timonsku @anool That worked! Thanks. Actually the import is perfect planes and all. Schematic import is also ok. I presume somehow i can massage the two into a project?

@pakakezu @timonsku @anool You have to run pcbnew as a separate instance, not as a part of a project.

No no, those are clearly @kicad_pcb files 😉

@arturo182 @timonsku @anool Hold on. I think I'm missing something? I still have to install some plugin? I just installed Version: (6.0.0-rc1-140-g6ecdbbb1da), release build I'm looking forward for this feature, because I'd rather import some old projects instead of redrawing them.

@timonsku @anool It is

@colinoflynn Using old component trays as support is genius. No more components in a puddle at the bottom.

New batch of ChipSHOUTERs, here applying one of the 3 different coatings used to keep your hacker hands safely away from the high voltage even in extreme failure modes. We've managed to thread the needle on supply chain issues so far to keep stuff moving.

@kynape Well reminds me of one of those "plate hho generator"-s. Alternating positive and negative plates, or even leaving neutral plates in between. Sure looks like stainless.

So the NAVITEL R600 has some interesting design choices. It has two batteries. One in the base and one in the camera. When the camera is mounted the two batteries are connected in parallel. This also means the battery voltage is always exposed in the contacts.

The charger for my NAVITEL R600 exploded in 30m use in vehicle. I sure hope they make better cameras than chargers. The fuse did not go. It was used in a 12V vehicle and is rated for 24V anyway. The capacitor and the charger ic is gone.

Some extra peeling power.

New ic came in from china. It does blink but still does not work. Some configuration may be needed. This is a good resource. #msg1300415" target="_blank" rel="nofollow noopener">eevblog.com/forum/projects…

Oh no. I have to order smaller 0.3mm balls.

Earthing the power supply too literally...

@FauthNiklas Does it have some internal hepa filter or you have to ventilate the whole room?

@ktemkin @GSGlabs We have the one from Eurocircuits. But seems to big most of the time. And when working on small boards heats my wrist to an uncomfortable temperature.

Proprietary BT module pinout with CSR8670CG and rfx2401c from expensive motorcycle intercom company. Aparently this module died in mine. Will try reballing.
