Krishna Swaroop Dhulipalla

This couldn't have come at a better time! 17,000 Part Database being served beautifully using KiCAD-Prism :) Library Manager UI & Remote Symbol Placement coming soon!! @i2cjak @yacineMTB @blind_via

New customers, new missions!! 🚀🚀

@gareebscientist :33

Very cool announcement from pixxel and sarvam, but I'm more curious about this new satellite bus, It seems to have 2 imaging telescopes? 3? Or is it laser communication? Lot of questions

@yukuyuku4123 Check this out as well: github.com/krishna-swaroo… :3

KiCanvasっていうKiCadのWebビューワーまじ神 後輩の回路確認わざわざデータダウンロードしなくて済むし軽いしまじで神 ほんと神(語彙力の欠如)

Coming soon to KiCAD-Prism! Self-Hosted Remote Libraries for everyone! All thanks to the amazing bug fixes by the KiCAD Dev Team and Huaqiu Devs! github.com/krishna-swaroo…

@ATaylorFPGA Nvm just went through the Exostiv specs. It’s a 4x16.25Gbps SerDes Link

@ATaylorFPGA 10/25GbE from the ZU+ to a 4x25GbE Link? Spicy!!

Image processing and a little fun with the Exostiv probe

@StableMab @i2cjak Silicon-on-Insulator (SoI) Node as well

@i2cjak How is it radiation tolerant ? Is it due to the 18nm node ?

look at how fucked up this bga is. good lord. but cool part, ST's newest w/ machine learning accelerator, on die NVM, 18nm. very radiation tolerant. in use on Starlink ALREADY

@i2cjak CYPD3177 changed my life

lowkey Europe was right for mandating USB-C for everything

Dozens of accounts on social media have been blocked & hundreds of posts have been taken down on the orders of the govt, just because they were critical of the govt or Modi. This is on top of control over mainstream media. This is in many ways worse than the Emergency.

:3

@will_whang You need an NDA to get access to the datasheet

and still no full datasheet available, fuck you

This is perfect - I was looking for NTB PCIe Switch for a small NUC PC cluster, and this is basically a dedicated PCIe network switch if you think about it.

@i2cjak Pipe dream

love when board bring-up has basically zero hiccups. amazing.

GODDAMN YOU NXP! HOW IS THE BRINGUP ALWAYS SO DOGSHIT😭😭😭

@i2cjak 1.6mm

gun pointed at yo head, favorite PCB thickness

Let’s gooo!!!!

@zackslab @i2cjak Such fun much wow

I FORMALLY CHALLENGE THEE (@i2cjak) TO AN EE DESIGN CHALLENGE (rendered in the TONE of an i2cjak wannabEE ARTICLE): ANON… I HAVE A PROPOSAL. a DESIGN CHALLENGE. a TEST of SKILL. a TEST of GRIT. a TEST of whether you are a REAL ELECTRONICS ENGINEER or merely someone who COPY PASTAS application notes written by some TI intern named KYLE. let me set the stage... imagine a world where you need to convert 12v into 48v. this is not a crazy number. this is just BOOSTING a voltage. people have been doing this since before your GREAT GREAT grandparents knew what a transistor was (i2cjack just turned 14). and yet… what does an i2cjak do? he goes to MOUSER (he was banned from digikey) and he types: "BOOST CONVERTER" he grabs some $6.37 switching regulator IC that hardly has any stock, has 87 internal op amps, slope compensation, cmc, undervoltage lockout, soft start, thermal shutdown, brownout detect, a coffee maker, and a SMALL GOBLIN that tunes the loop compensation FOR HIM. he then looks himself in the mirror and calls himself A HARDTECH ENGINEER. he slaps down one inductor, a diode, some caps, and a prayer. NO. not today anon. THE CHALLENGE: • design a 12v to 48v dc/dc converter • highest efficiency @ 10A/480W wins but there are RULES. and they are CRUEL. RULES: • NO SWITCHING REGULATOR ICS • no boost controllers • no flyback controllers • no "smart power stages" • no little black boxes that say "PWM controller" on the datasheet • if the datasheet contains the phrase "switching regulator" you are DISQUALIFIED ALLOWED COMPONENTS: • a microcontroller • gate drivers (maybe) • power transistors • diodes • discrete analog • discrete logic • passives THE CONTROL LOOP: • must be written entirely BY YOU • no OTS analog compensation network that MAGICALLY stabilizes everything YOU WILL: • fab the board at a fab house of your choice • solder it YOURSELF • measure voltages YOURSELF • measure currents YOURSELF • perform step response YOURSELF • perform load sweeps YOURSELF • measure EFFICIENCY YOURSELF • you know, REAL EE SHIT YOURSELF like the founding fvcking fathers intended. ANY TOPOLOGY IS FAIR GAME: • boost • flyback • forward • pushpull • interleaved • some cursed topology you invented at 3am i do not care. but it must convert 12v to 48v. and it must fvck. SCORING: highest measured efficiency @ 10A wins (adjusted for BOM cost). WHY THIS IS FUN: because suddenly all the stuff those nice little regulator ICs do for you becomes YOUR PROBLEM. you must engineer. ELECTRICALLY. things like: • current limiting • duty cycle saturation • loop stability • slope compensation • dead time • gate drive timing • startup behavior • transient response EXPECTED OUTCOMES: • REAL EE is harder than it looks, i might fail. you might fail. BUT WE ALL LEARN. • writing a control loop from scratch is CURSED. • switch node ringing is DEMONIC. and guess what i2cjak, the inductor you'll pick will be WRONG!!! your efficiency will mysteriously drop by 15% because physics HATES YOU!!! but, you are a MANIAC. and you will eventually produce something BEAUTIFUL even IF it is covered in your BLOOD, SWEAT, AND TEARS. so anon. do you ACCEPT the challenge? or will you retreat back to your TPS5430 application notes like a frightened little B*TCH? MAY THE SUPREME WIZARD OF ELECTRONS WIN!!!

F

Is there a Meshtastic/MeshCore scene in Bangalore?
