@RantyHighwayman @bricycle As usual the Dutch have it sorted struykverwoinfra.nl/productselecto…

I do like this visual and textured warning of the upcoming bollard as someone who has clattered into my fair share.

Time for a rethink? There is another way...

The non-Dutch mind can't comprehend this 🚲 #Festival #ZwarteCross #bicycles

@bricycle Beautiful to see a cyclops in place. I'd like to see future ones sub 40° splays & maximise the useable space of the lanes.

If we look closely at the kerbs on the Cyclops junction in Preston, you can see the effort made to make it legible to visually impaired people. Full kerb heights, colour, and island separation of cycling and walking space even though they cross at the same time. Best practice IMO

@RantyHighwayman @London_Cycling I can imagine what it would find but I can't imagine how many tens of thousands of pages that report would come out as 😅

TfL publishes its review of all 164 'bus stop bypasses': content.tfl.gov.uk/bus-stop-bypas… Summary: "extremely low risk", next steps: educate cyclists on appropriate behaviour, update older bypasses, clear info to bus passengers, more research. More on risk in 🧵 ...

@H_H_Gray It only took a took a few weeks for the first death to happen. A man on his bike mown down at virtually the same spot that a passenger in a hugh speed crash was killed later on. gmp.police.uk/cy-GB/news/gre…

Hyde Road is one of the most dangerous places in Manchester In 2021 Manchester City Council spent £6 million making it even more dangerous Decisions have consequences

What Hyde Road *should* look like vs. what's been done to it Thanks @InfraCGI for the GIF #TGIF

Wow. I’ve just cycled the length of the #Chorlton cycleway in my lunch break to check on progress and bar the section over the bridge I only saw one cone and one barrier. So good to see the pavements and road free of all the clutter. 🐝 Eric Wright busy working to finish some of the surfacing but almost a clear run. It’s been a really hard and frustrating process and the level of vitriol we’ve had thrown at us as Councillors has been phenomenal. Whilst it may not be perfect, as someone who has cycled this route more days than not for 45 years, I have no doubt that the changes will not just improve lives, but will save lives! Cleaner air and safer, healthier more sustainable travel. And ultimately, as people’s confidence grows in using it, I’ve no doubt it will help reduce congestion and increase footfall for local traders. If not, I’ll eat my cycling hat!

@Zapaman @WalkRideGM Theres another new 5g mast a few 100m further up next to McDs also built after the widening. Same story. It was promptly crashed into at god knows what speed. That time a passenger died & left the mast near to collapse. Again rebuilt from scratch. Madness express.co.uk/news/uk/163901…

@Zapaman @WalkRideGM Back when I made this image that mast had only been installed a couple of weeks earlier.it didn't exist when MCC widened the Rd. It promptly got crashed into at 50/60 mph and totally destroyed. Its since been rebuilt in the same spot. Tldr : yes

@TheWrongDetail @WalkRideGM Dear oh dear! twitter.com/InfraCGI/statu…

Stockport Council pretend they can't build cycle lanes on the A6 Unfortunately for them, we already have the drawings to show it's possible!

@paulgannonbike Probably for drainage but could have been made much more forgiving with a better choice of kerbs.

What is that nasty, narrow gap for? A contra-flow?

There are nearly four times as many traffic lights per capita in Los Angeles than in Amsterdam. Stop-start movement is the price everyone pays for higher speeds. When most streets are 30 km/h or less, such interventions are rarely needed—allowing everything to flow more freely.

Jokes aside this is exactly what every UK high street should be looking like 👏 Amazing public realm!

Another CYCLOPS opens in Manchester! Sandy Lane is the final junction of the Chorlton Cycleway

This. This is what I want.

A CGI to show how space could be reallocated to create protected bike lanes and crossings on Route 6 through Fairhaven Massachusetts

@alex_velovelo1 I agree, but NL is so far ahead of the UK and the UK is so far down a different rabbit hole that it wouldn't be just the odd driver, it would be hundreds a day. There's no right or wrong answer.

@InfraCGI Almost 10/10. In NL there would be no dangerous bollards in the cycle path. Safer to allow the odd a'hole driver to break the law than have an oldster come a cropper via the bollard.

A CGI to show how a modal filter can be a beautiful addition to the local streetscape whilst doing its job of preventing cut through motor traffic and still allowing active travel users to pass through unhindered. 🚲🌳

@fatimasuhyl 3dsmax

A quick transformation for a Patreon subscriber to show how protected bike panes could be added to Lido Boulevard in NY.
